- Shivraj Brass International is engaged in Exporting and Manufacturing of Brass casting parts, Bronze casting parts, Aluminum casting parts and Copper casting parts.
- The metal casted parts are then partly or fully machined to comply with standards like ISO, DIN, JIS, EN, ASTM & other international standards.
- We manufacture metal casting parts with high quality materials sourced from trusted vendors and that which has longer lifespan and thoroughly tested by our Quality Control Team with Quality Testing Equipments.
- We are involved in manufacturing of the metal casting parts of brass, bronze, aluminum and copper in India since two decade.
- The method that we use for castings are green sand casting, centrifugal casting, investment casting, and pressure die castings.
- Our castings are partly or fully machined in our CNC, VMC and semi automatic machines to meet the required need of our customers.
- Our casted parts are used in industries like automotive, pump systems, mining, oil and gas, marine, electrical connections, lightening and grounding connections, water distribution and drainage, door and window hardwares, etc.
Manufacturing Process
High Quality Raw Material
Casting Process
Casted Part and Precision Machined Part
Technical Description
BRASS CASTING PARTS :
| Brass Casted Fittings | Brass Casted Valves | Brass Casted Nuts and Bolts |
| Brass Casted Hardware Parts | Brass Casted Earthing Parts | Brass Casted Thrust Washers |
| Brass Casted Bushing and Bearings | Brass Sanitary and Plumbing Fittings | Brass Casted Lightning and Grounding Parts |
| Many other Parts |
BRONZE CASTING PARTS :
| Bronze Casted Fittings | Bronze Casted Valves | Bronze Casted Nuts and Bolts |
| Bronze Casted Marine Parts | Bronze Casted Earthing Parts | Bronze Casted Thrust Washers |
| Bronze Casted Bushing and Bearings | Bronze Sanitary and Plumbing Fittings | Bronze Casted Lightning and Grounding Parts |
| Many other Parts |
ALUMINUM CASTING PARTS :
| Aluminium Casted Hardware Parts | Aluminium Casted Earthing Parts | Aluminium Casted Washers |
| Aluminium Casted Fittings | Aluminium Casted Nuts and Bolts | Aluminium Casted water drainage systems |
| Aluminium Casted Lightning and Grounding Parts | Aluminium Sanitary and Plumbing Fittings | Aluminium Casted Bushing and Bearings |
| Many other Parts |
COPPER CASTING PARTS :
| Copper Casted Lightning and Grounding Parts | Copper Sanitary and Plumbing Fittings | Copper Marine Parts |
| Copper Casted Pistons | Copper Casted Fittings | Copper Casted Nuts and Bolts |
| Copper Casted Casted Bushing and Bearings | Copper Casted Earthing Parts | Copper Casted Thrust Washers |
| Many other Parts |
| Resistance To Deterioration and Fatigue |
| Excellent thermal conductivity |
| Superb mechanical properties |
| Economic for Mass Production of Parts |
| Superb Durability and Endurance |
| Good aesthetic appeal |
| Threads of the Casted parts after machining are as per International Go & Not-Go Standards |
| Strong And Reusable Threads |
| Standards like ISO, GB, DIN, EN, JIS, ASTM |
| Any Other Standards as per Customers' needs and specifications. |
| ISO Metric(mm), NPS, NPT, PG, BSW(inches), BA, BSF, BSB, BSP, BSPT, UNC, UNF, UNEF |
| Any Other Thread Types as per Customers' needs and specifications. |
VALUE ADDED SERVICES:
| Sand Blasting |
| Mechanical Assembly |
| Deburring |
| Any Other Value Added Services as per Customers' needs and specifications |
| BRASS: | CuZn39Pb3, CuZn39Pb2, CuZn38Pb1.5, CuZn40Pb2, CuZn37, MS 58, BS2874, BS 249 (Type I), C35300, C36000, C36500, C37000, C3603, C3604, CZ121, CZ122, CZ124, CZ128, CZ131, CW606N, CW612N, CW614N, CW617N |
| BRONZE: | Aluminium Bronze: C95200, C95300, C95400, C95500, C95800, C63000 |
| High Leaded Tin Bronze: C93200, C93400, C93500, C93700, C93800, C94300 | |
| Leaded Bronze: C92200, C92300, C92600, C92700 | |
| Tin Bronze: C90300, C90500, C90700 | |
| Manganese Bronze: C86200, C86300, C86500 | |
| Phosphor Bronze: C54400, C51000, C90700, C92700, C90800, C90810 | |
| Silicon Bronze: C64200, C65100, C65500, C87300, C95600 | |
| ALUMINIUM: | LM2, LM6, LM25, A356, A380, Commercial Aluminium and other grades |
| COPPER: | C81500, C82200, C82800, C110 and other grades |
| Natural, Nickel Plated, Electro-Tin Plated, Zinc Plated, Chrome Plated, Copper Plated |
| Any Other Specific Surface Plating / Finish as per Customers' needs and specifications |
| Petochemical Industries | Oil & Gas Industry | Marine Industry |
| Plumbing and Pipe Industry | Automotive Industry | Aerospace Industry |
| Mining Industry | Electrical Industry | Railway Industry |
| Other Industries |
| In India as well as USA, UK, Europe, Canada, Australia and Middle East. |
| We Export Metal casting parts to other countries as well. |
